Gobo System

1 Rotating gobo wheel with 7 rotatable and interchangeable

Gobo size 22.7mm (external)/14mm (inner)

1 Static gobo wheel with 12 gobos plus open

Prism System

3-Facet prism with variable speed and direction

8-Facet prism with variable speed and direction

Control System

22/26 DMX channels USITT DMX-512

DMX512, master-slave, or auto operation

DMX recorder and edit function integrated

RDM available (Remote Device Management)

Shielded input signal protection for stable

signal without interference

3-Pin XLR DMX connectors IN/OUT

Wash System

Frost filter (Hybrid effect for wash)

Even and soft coverage

Software Update

Software up-datable through DMX connectors

Muilt units up-datable in daisy chain

Display System

2.8" TFT LCD display

5 Control buttons

180°Reversible for LCD display

DMX signal and error monitoring indicators

Cooling System

Advanced cooling system integrated aluminum and copper with liquid

Efficient low noise self adjusting fan cooling system

Constant temperature readout and management function

Over temperature protection management

Power Supply

Electronic supply with active PFC

AC100-240V 50/60Hz

PowerCON IN/ OUT with power switch and fuse

430W Power consumption

Housing

High intension moulded fire proof ABS PC

Skeleton made of aluminum and steel metal plates

Two side handles on base

Exterior finish: Black

Installation

2*1/4 turn fastening Omega Clamps

(Adaptable vertically and horizontally)

1*Safety attachment point

Operating Condition

-25℃ to 45℃ ambient temperature

IP20 protection rating

Weight

N.W.: 22.5kg

G.W.: 25.5kg

Dimensions

Product Dimensions: 270(D)*381(W)*650(H)mm

Packing Dimensions: 520(D)*630(W)*500(H)mm
