POWER SUPPLY

AC110-240V,50/60Hz electronic auto-ranging

Power consumption: 850W

OPTIC

Light source: High power 700W white light LED,6800K

Iris: Motorized,linear

Zoom angle: 4.5 degree to 50 degree linear zoom

EFFECT SECTION

CMY+CTO color mixing system

1x color wheel: 7 fixed colors + white, half-color with rainbow effect

1x rotating gobo wheel:6 replaceable rotating gobos + white with gobo shaking

1x fixed gobo wheel: 8 fixed gobos + white with gobo shaking

Prism wheel: Rotating 3-faced prisms +6-faced linear prism, two prisms can be overlayed

1x animation wheel with water, wave and flame effects, rotatable and replaceable

FRAMING SYSTEM

Framing shutters: 4x framing shutters, each individually controllable

Framing module can be rotated at 90°

CONTROL AND PROGRAMMING

With RDM function

Channel:36 standard DMX512 channels

MOVEMENT

Pan scanning::540°or 630° (16 bit resolution)

Tilt scanning:270° (16 bit resolution)

PACKING DIMENTION

Dust-proof and oil-proof design

Size:510Lx345W x 800H(mm)

Net weight: 40kgs

Gross weight: 43kgs
