Light Source: OSRAM SIRIUS HRI 461W lamp

2°Beam angle

PAN movement: 540° (8/16 bit)

PAN movement: 270° (8/16 bit)

Fast, quiet, smooth and precise 3-Phase motors

Color System

1 Color wheels with 14 dichroic colors plus open (half color mode available)

7-Color effect wheel

Gobo System

1 Static gobo wheel with 13 gobos plus open and gobo shaking

Prism System

16-Facet prism with variable speed and direction

8+16-Facet prism with variable speed and direction

Strobe Effect

0-20Hz high speed shutter/strobe effect with variable speed

Dimming System

0-100% Smooth linear mechanichal dimming

Control System

16/22 DMX channels USITT DMX-512

RJ45 ethernet connecotrs IN/OUT (Optional)

3-Pin XLR connectors IN/OUT

Display System

2.4" Touch screen TFT LCD display

4 Control buttons

180°Reversible for LCD display

Display auto OFF

Cooling System

Advanced cooling system

Efficient low noise self adjusting fan cooling system

Constant temperature readout and management function

Over temperature protection management

Power Supply

Electronic ballast: OSRAM PT SIRIUS 461W-Unishape

AC100-240V 50/60Hz

700W Power consumptiom

Installation

2*1/4 turn fastening Omega Clamps (Adaptable vertically and horizontally)

1*Safety attachment point

Weight

N.W.: 21.4kg

G.W.: 25.7kg

Dimensions

Product Dimensions: 280(D)*400(W)*632(H)mm

Packing Dimensions: 495(D)*595(W)*680(H)mm
